HCPL-0454-500E

Name: HCPL-0454-500E
Brand: Broadcom Limited
SKU: 141777
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-0454-500E
Manufacturer	Broadcom Limited
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISOLATOR 3.75KV TRANS 8-SO
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	3750Vrms
Minimum DC Current Transfer Ratio	21% @ 16mA
Switching Turn-On and Turn-Off Time	200ns, 300ns
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	20V
Channel Output Current	8mA
Forward Voltage	1.5V
Continuous forward current- Max	25mA
Temperature Range - Operating	-55°C to 100°C
Mounting	SMD (SMT)
Case / Package	8-SO
Win Source Part Number	016826-HCPL-0454-500E
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	HCPL-0454-500E
Introduction Date	May 31, 2005
ECCN	EAR99
Country of Origin	Philippines, Singapore
Estimated EOL Date	2023
Quantity per package	1,500
Ultra Librarian 3D Model	Ultra Librarian HCPL-0454-500E CAD Model

Alternative Products

Description

The HCPL-0454-500E from Broadcom Limited is an optoisolator with a Win Source Part Number of 016826.

Packaging: Reel - TR
Mounting: SMD (SMT)
Output Type: Transistor
Forward Voltage: 1.5V
Input Type: DC
Isolation Voltage: 3750Vrms
ECCN: EAR99 compliant
Operating Temperature: -55°C to 100°C
Case/Package: 8-SO
Minimum DC Current Transfer Ratio: 21% @ 16mA
Switching Turn-On Time: 200ns
Switching Turn-Off Time: 300ns
Maximum Output Voltage: 20V
Channel Output Current: 8mA
Continuous Forward Current-Max: 25mA
