HCPL-0452-000E

Name: HCPL-0452-000E
Brand: Broadcom Limited
SKU: 141767
Availability: InStock
Rating: 4.85 (292 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-0452-000E
Manufacturer	Broadcom Limited
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	Optocoupler DC-IN 1-CH Transistor With Base DC-OUT 8-Pin SOIC Tube / OPTOISOLATOR 3.75KV TRANS 8-SO
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Tube/Rail
Status	Active
Number of Channels	1
Isolation Voltage	3750Vrms
Minimum DC Current Transfer Ratio	15% @ 16mA
Switching Turn-On and Turn-Off Time	1μs, 1μs (Max)
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	20V
Channel Output Current	8mA
Forward Voltage	1.5V
Continuous forward current- Max	25mA
Temperature Range - Operating	-55°C to 100°C
Mounting	SMD (SMT)
Case / Package	8-SO
Win Source Part Number	016823-HCPL-0452-000E
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	100
Family Name	HCPL-0452
Introduction Date	May 31, 2005
ECCN	EAR99
Country of Origin	Singapore, Philippines
Halogen Free	Compliant
Estimated EOL Date	2026
Ultra Librarian 3D Model	Ultra Librarian HCPL-0452-000E CAD Model

Alternative Products

Description

The Broadcom Limited 016823-HCPL-0452-000E is a transistor output isolator with a minimum DC current transfer ratio of 15% at 16mA. It has an isolation voltage of 3750Vrms and is mounted on SMD (SMT).

DC Current Transfer Ratio (Minimum): 15% @ 16mA
Isolation Voltage: 3750Vrms
Mounting Type: SMD (SMT)
Output Voltage (Maximum): 20V
Channel Output Current: 8mA
Switching Turn-On Time: 1μs
Switching Turn-Off Time: 1μs
Package: 8-SO
Popularity: High
Application: Isolators
