Same model may have multiple batches, images only for reference.

HCNW3120-500E

Name: HCNW3120-500E
Brand: Broadcom Limited
SKU: 141726
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCNW3120-500E
Manufacturer	Broadcom Limited
Catalog	Isolators - Gate Drivers
Description	OPTOISO 5KV GATE DRIVER 8DIP GW
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Technology	Optical Coupling
Number of Channels	1
Isolation Voltage	5000Vrms
Common Mode Transient Immunity (Min)	25kV/μs
Propagation Delay tpLH / tpHL (Max)	500ns, 500ns
Pulse Width Distortion (Max)	300ns
Rise and Fall Time	100ns, 100ns
Current - Output High, Low	2A, 2A
Current - Peak Output	2.5A
Forward Voltage	1.6V
Continuous forward current- Max	25mA
Supply Voltage - Operating	15 V to 30 V
Temperature Range - Operating	-40°C to 100°C
Mounting	SMD (SMT)
Case / Package	8-DIP Gull Wing
Approvals	CSA, IEC/EN/DIN, UR
Win Source Part Number	016816-HCNW3120-500E
Family Name	HCNW3120
Introduction Date	November 01, 2003
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Compliant
Estimated EOL Date	2023
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Quantity per package	750
Ultra Librarian 3D Model	Ultra Librarian HCNW3120-500E CAD Model

Description

The Broadcom Limited 016816-HCNW3120-500E is an optical coupling technology electronic component.

Forward Voltage: 1.6V
Channels: 1
Isolation Voltage: 5000Vrms
Application: Isolator
Popularity: High
Continuous Forward Current-Max: 25mA
Quantity per Package: 750
