ACPL-M61L-560E Real Image ACPL-M61L-560E real image
Same model may have multiple batches, images only for reference.
ACPL-M61L-560E Real Image ACPL-M61L-560E real image
ACPL-M61L-560E Real Image ACPL-M61L-560E real image
Same model may have multiple batches, images only for reference.

ACPL-M61L-560E

Part No ACPL-M61L-560E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description Ultra Low Power 10 MBd Digital CMOS Optocouplers | OPTOISO 3.75KV PUSH PULL 5SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Minimum) 20kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Current - Output / Channel 10mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Maximum) 80ns, 80ns
Rise / Fall Time 12ns, 12ns
Voltage - Forward (Vf) 1.3V
Current - DC Forward (If) (Maximum) 8mA
Supply Voltage (V) 2.7V ~ 5.5V
Temperature Range - Operating -40°C ~ 105°C
Mounting Style SMD
Manufacturer Package 6-SOIC , 5 Leads
Supplier Device Package 5-SO
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1135412-ACPL-M61L-560E
Manufacturer Homepage www.avagotech.com
Family Name ACPL-M61L
Introduction Date September 22, 2009
ECCN EAR99
Country of Origin Philippines, Singapore
Halogen Free Not Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ACPL-M61L-560E CAD Model

Description

The Broadcom Limited ACPL-M61L-560E is a 10MBd, 3750Vrms Push-Pull, Totem Pole output type DC input type Isolator that is designed for surface mount and has a 5-SO package.

  • Package: reel
  • Operating Temperature Range: -40°C to 105°C
  • Current Output/Channel: 10mA
  • Current DC forward (If) (maximum): 8mA
  • Propagation Delay tpLH / tpHL (maximum): 80ns, 80ns
  • Common Mode Transient Immunity (minimum): 20kV/μs
  • Introduction Date: September 22, 2009
  • ECCN: EAR99
  • Estimated EOL Date: 2024
  • Popularity: high
  • Supply and Demand Status: balance
