Same model may have multiple batches, images only for reference.
SRF4532-220Y Real Image
Same model may have multiple batches, images only for reference.

SRF4532-220Y

Part No SRF4532-220Y
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Description CMC 22UH 200MA 2LN 1KOHM SMD
Datasheet
SRF4532-220Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Estimated Pruduction Lead Time 31 Weeks
Features 2 Line Common Mode Choke Surface Mount 1 200mA DCR 2.65Ohm
Manufacturer Bourns Inc.
Series SRF4532
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package Horizontal, 4 PC Pad
Family Name SRF4532
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Other Part Number SRF4532-220YDKR, SRF4532-220YTR, SRF4532220Y, SRF4532-220YCT
Quantity per package 500
Popularity High
Supply and Demand Status Balance
Win Source Part Number 897381-SRF4532-220Y
Ultra Librarian 3D Model Ultra Librarian SRF4532-220Y CAD Model

Description

The Bourns Inc. SRF4532 series is a 2 line common mode choke surface mount filter.

  • Inductance: 220Y
  • DCR: 2.65Ohm
  • Current Rating: 1 200mA
  • Package: horizontal, 4 PC pad
  • Mounting: surface mount
  • Temperature Range: -40°C ~ 125°C
  • REACH: unaffected
  • Popularity: high
  • Supply and Demand Status: balance
  • Quantity per Package: 500
  • Estimated Production Lead Time: 31 weeks
