SMAJ28A Real Image SMAJ28A Real Image
Same model may have multiple batches, images only for reference.
SMAJ28A Real Image SMAJ28A Real Image
SMAJ28A Real Image SMAJ28A Real Image
Same model may have multiple batches, images only for reference.

SMAJ28A

Part No SMAJ28A
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 28VWM 45.4VC DO214AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Bourns Inc.
Standard Package 1
Category Circuit Protection
Family TVS - Diodes
Series SMAJ
Packaging Reel
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 28V
Voltage - Breakdown (Min) 31.1V
Voltage - Clamping (Max) @ Ipp 45.4V
Current - Peak Pulse (10/1000µs) 8.8A
Power - Peak Pulse 400W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AC SMA
Manufacturer Device Package SMA (DO-214AC)
Catalog SMAJ Series
Win Source Part Number 095255-SMAJ28A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Series *
Package Tape & Reel (TR)
Product Status Active
Grade -
Ultra Librarian 3D Model Ultra Librarian SMAJ28A CAD Model

Description

The Bourns Inc. Zener diode, part of the SMAJ series, is a high-quality TVS diode that is ideal for general purpose applications.

  • Channel: Unidirectional
  • Reverse Standoff Voltage: 28V
  • Breakdown Voltage: 31.1V
  • Voltage Clamping @ Ipp: 45.4V
  • Peak Pulse Power: 400W
  • Current Peak Pulse: 8.8A
  • Standard Package: 1
  • Operating Temperature: -55°C to 150°C (TJ)
  • Package: DO-214AC SMA
  • Packaging: Reel
  • Mounting: SMD/SMT
  • Supply and Demand: Balanced
