SF-0603S050-2 Bourns Inc. SF-0603S050-2 Real Image SF-0603S050-2 real image
Same model may have multiple batches, images only for reference.
SF-0603S050-2 Bourns Inc. SF-0603S050-2 Real Image SF-0603S050-2 real image
SF-0603S050-2 Bourns Inc. SF-0603S050-2 Real Image SF-0603S050-2 real image
Same model may have multiple batches, images only for reference.

SF-0603S050-2

Part No SF-0603S050-2
Manufacturer Bourns Inc.
Catalog Fuses
Description FUSE BOARD MNT 500MA 50VDC 0603 / SF-0603S Series - Slow Blow Surface Mount Fuses
Datasheet
SF-0603S050-2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Bourns Inc.
Packaging Reel
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 500mA
Voltage Rating - DC 50V
Response Time Slow Blow
Manufacturer Package 0603
Mounting Style SMD
Breaking Capacity at Rated Voltage 50A
Melting I2t 0.009
Approvals UL
Temperature Range - Operating -20°C ~ 105°C
Dimension 0.063" L x 0.032" W x 0.018" H (1.60mm x 0.80mm x 0.45mm)
DC Cold Resistance 0.175 Ohms
Part Number Series SF-0603
Manufacturer Pack Quantity 5,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 802868-SF-0603S050-2
Ultra Librarian 3D Model Ultra Librarian SF-0603S050-2 CAD Model

Description

This is a board mount fuse with the Win Source Part Number 802868-SF-0603S050-2.

  • Packaging: Reel
  • Mounting Style: SMD
  • Fuse Type: Slow Blow
  • Voltage Rating: 50V
  • Melting I2t: 0.009
  • Approvals: UL
  • DC Cold Resistance: 0.175 Ohms
  • Temperature Range: -20°C to 105°C
  • Dimension: 0.063" L x 0.032" W x 0.018" H (1.60mm x 0.80mm x 0.45mm)
  • Package: 0603
  • Supply and Demand Status: Balanced
  • Manufacturer Pack Quantity: 5,000
  • MSL Level: 1 (Unlimited)
  • Current Rating: 500mA
  • Breaking Capacity: 50A
  • Part Number Series: SF-0603
