MF-SM050-2-006

Part No MF-SM050-2-006
Manufacturer Bourns Inc.
Catalog PTC Resettable Fuses
Description PTC RESET FUSE 60V 500MA 2SMD / Polymeric PTC Resettable Fuse 60V 500 mA Ih Surface Mount 2-SMD
Datasheet
MF-SM050-2-006 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>PTC Resettable Fuses
Mfr Bourns Inc.
Series Multifuse®, MF-SM
Package Tape & Reel (TR)
Type Polymeric
Voltage - Max 60V
Current - Max 40 A
Current - Hold (Ih) (Max) 500 mA
Current - Trip (It) 1 A
Time to Trip 4 s
Resistance - Initial (Ri) (Min) 350 mOhms
Resistance - Post Trip (R1) (Max) 1.4 Ohms
Temperature Range - Operating -40°C ~ 85°C
Ratings AEC-Q200
Mounting SMD (SMT)
Package / Case 2-SMD
Dimension 0.287" L x 0.214" W (7.31mm x 5.44mm)
Thickness (Max) 0.125" (3.18mm)
Approval Agency cURus, TUV
Base Product Number MF-SM
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
Standard Package 2,000
Win Source Part Number 1108221-MF-SM050-2-006
Ultra Librarian 3D Model Ultra Librarian MF-SM050-2-006 CAD Model

Description

The MF-SM050-2-006 is a PTC resettable fuse from Bourns Inc.

  • Type: Polymeric
  • Function: protect electronic circuits from overcurrent conditions
  • Voltage Rating: 60V
  • Maximum Current: 40A
  • Current Hold: 500mA
  • Current Trip: 1A
  • Time to Trip: 4s
  • Package Type: 2-SMD
  • Packaging: Tape and Reel (TR)
  • Temperature Range: -40°C to 85°C
