Same model may have multiple batches, images only for reference.
CFN1206AFX-R005ELF Real Image
Same model may have multiple batches, images only for reference.

CFN1206AFX-R005ELF

Part No CFN1206AFX-R005ELF
Manufacturer Bourns Inc.
Catalog Chip Resistor - Surface Mount
Description RESMETALFOIL A 1206 R005 1% 1W T / 5 mOhms ±1% 1W Chip Resistor 1206 (3216 Metric) Automotive AEC-Q200, Current Sense Metal Foil
Datasheet
CFN1206AFX-R005ELF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors>Chip Resistor - Surface Mount
Mfr Bourns Inc.
Series CFN-A
Package Tape & Reel
Resistance 5 mOhms
Tolerance ±1%
Power (Watts) 1W
Composition Metal Foil
Features Automotive AEC-Q200, Current Sense
Temperature Coefficient ±100ppm/°C
Temperature Range - Operating -55°C ~ 155°C
Package / Case 1206 (3216 Metric)
Supplier Device Package 1206
Ratings AEC-Q200
Dimension 0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max) 0.028" (0.70mm)
Number of Terminations 2
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.21.0030
Other Names 118-CFN1206AFX-R005ELFCT,118-CFN1206AFX-R005ELFTR,118-CFN1206AFX-R005ELFDKR
Standard Package 4,000
Win Source Part Number 1051849-CFN1206AFX-R005ELF
Ultra Librarian 3D Model Ultra Librarian CFN1206AFX-R005ELF CAD Model

Description

The Bourns CFN-A is a chip resistor with a resistance of 5 mOhms and a tolerance of ±1%. Bourns is the manufacturer.

  • Resistance: 5 mOhms
  • Tolerance: ±1%
  • Temperature Coefficient: ±100ppm/°C
  • Power Rating: 1W
  • Application: Automotive
  • AEC-Q200 Rated: Yes
  • Height: 0.028 inches (0.70mm)
  • Package Dimension: 1206 (3216 Metric)
  • Temperature Range: -55°C to 155°C
  • Number of Terminations: 2
  • ECCN: EAR99
  • Packaging: Tape and reel (4,000 units)
  • RoHS: Unaffected
  • HTSUS: 8533.21.0030
