SRR1280-1R4Y

Part No SRR1280-1R4Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR1280
Package Tape & Reel (TR)
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 1.4 µH
Tolerance ±30%
Current Rating (Amps) 9.8 A
Current - Saturation (Isat) 12A
Shielding Shielded
DC Resistance (DCR) 9.8mOhm Max
Q @ Freq 24 @ 7.96MHz
Frequency - Self Resonant 80MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.315" (8.00mm)
Base Product Number SRR1280
Standard Package 400
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273391-SRR1280-1R4Y
Ultra Librarian 3D Model Ultra Librarian SRR1280-1R4Y CAD Model

Description

The Bourns SRR1280-1R4Y is a shielded drum core inductor that is designed for use in power supplies and DC-DC converters.

  • Inductance: 1.4 microhenries
  • Current Rating: 9.8A
  • Tolerance: ±30%
  • DC Resistance: 9.8 milliohms
  • Supply and Demand Status: Limited
