Same model may have multiple batches, images only for reference.
SRP7030-5R6FM Real Image
Same model may have multiple batches, images only for reference.

SRP7030-5R6FM

Part No SRP7030-5R6FM
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP7030F
Package Tape & Reel
Product Status Obsolete
Type Molded
Material - Core Iron
Inductance 5.6 µH
Tolerance ±20%
Current Rating (Amps) 5 A
Current - Saturation (Isat) 6A
Shielding Shielded
DC Resistance (DCR) 45mOhm Max
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.299" L x 0.256" W (7.60mm x 6.50mm)
Height - Seated (Max) 0.118" (3.00mm)
Base Product Number SRP7030
Other Names SRP7030-5R6FMTR,SRP7030-5R6FMCT,SRP7030-5R6FMDKR,SRP70305R6FM
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273777-SRP7030-5R6FM
Ultra Librarian 3D Model Ultra Librarian SRP7030-5R6FM CAD Model

Description

The SRP7030-5R6FM is a fixed inductor designed for use in inductors, coils, chokes.

  • Series: SRP7030F
  • Package: Tape & Reel
  • Standard Package: 1,000
  • Type: Molded
  • Shielding: Shielded
  • Inductance: 5.6 µH
  • Height - Seated (Max): 0.118" (3.00mm)
  • Tolerance: ±20%
  • Material - Core: Iron
  • DC Resistance (DCR): 45mOhm Max
  • Operating Temperature: -55°C ~ 125°C
  • Dimension: 0.299" L x 0.256" W (7.60mm x 6.50mm)
  • ECCN: EAR99
  • MSL Level: 1 (Unlimited)
  • REACH Status: REACH unaffected
  • HTSUS: 8504.50.4000
  • Manufacturer: Bourns Inc.
