SRP3012C-100M Real Image
Same model may have multiple batches, images only for reference.

SRP3012C-100M

Part No SRP3012C-100M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP3012C-100M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP3012C
Package Tape & Reel
Material - Core Metal
Inductance 10 µH
Tolerance ±20%
Current Rating (Amps) 1.1 A
Current - Saturation (Isat) 1.4A
Shielding Shielded
DC Resistance (DCR) 520mOhm Max
Q @ Freq 10 @ 100kHz
Frequency - Self Resonant 24MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max) 0.047" (1.20mm)
Other Names 118-SRP3012C-100MCT,118-SRP3012C-100MTR,118-SRP3012C-100MDKR
Standard Package 4,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273987-SRP3012C-100M
Ultra Librarian 3D Model Ultra Librarian SRP3012C-100M CAD Model

Description

The Bourns Inc. 1273987-SRP3012C-100M is a fixed inductor that belongs to the SRP3012C series.

  • Inductance: 10 µH
  • Current Rating: 1.1A
  • Shielded: Yes
  • Tolerance: ±20%
  • Q @ Freq: 10 @ 100kHz
  • Frequency Self-Resonant: 24MHz
  • Mounting: SMD (SMT)
  • Packaging: Tape and Reel
  • Standard Package: 4,000 units
  • Nonstandard Package/Case Dimension: 0.138" L x 0.126" W (3.50mm x 3.20mm)
  • ECCN: EAR99
  • REACH: Unaffected
