Same model may have multiple batches, images only for reference.
SRP1265C-4R7M Real Image
Same model may have multiple batches, images only for reference.

SRP1265C-4R7M

Part No SRP1265C-4R7M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP1265C-4R7M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP1265C
Package Tape & Reel
Material - Core Metal
Inductance 4.7 µH
Tolerance ±20%
Current Rating (Amps) 20 A
Current - Saturation (Isat) 31A
Shielding Shielded
DC Resistance (DCR) 9.5mOhm Max
Q @ Freq 20 @ 100kHz
Frequency - Self Resonant 15MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.531" L x 0.496" W (13.50mm x 12.60mm)
Height - Seated (Max) 0.256" (6.50mm)
Other Names 118-SRP1265C-4R7MDKR,118-SRP1265C-4R7MCT,118-SRP1265C-4R7MTR
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274030-SRP1265C-4R7M
Ultra Librarian 3D Model Ultra Librarian SRP1265C-4R7M CAD Model

Description

The SRP1265C-4R7M is a shielded inductor from Bourns Inc. that is ideal for use in various applications such as power supplies, voltage regulators, and DC/DC converters.

  • Inductance: 4.7μH
  • Tolerance: ±20%
  • DC Resistance: 9.5mOhm max
  • Current Rating: 20A
  • Core Material: Metal
  • Temperature Range: -40°C to 125°C
  • Package/Case: Nonstandard
  • Mounting: Surface mount
