SRP1250-R56M Real Image
Same model may have multiple batches, images only for reference.

SRP1250-R56M

Part No SRP1250-R56M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP1250-R56M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP1250
Package Tape & Reel (TR)
Type Drum Core, Wirewound
Material - Core Iron
Inductance 560 nH
Tolerance ±20%
Current Rating (Amps) 36 A
Current - Saturation (Isat) 55A
Shielding Shielded
DC Resistance (DCR) 1.5mOhm Max
Temperature Range - Operating -55°C ~ 150°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Max) 0.232" (5.90mm)
Base Product Number SRP1250
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274049-SRP1250-R56M
Ultra Librarian 3D Model Ultra Librarian SRP1250-R56M CAD Model

Description

The SRP1250-R56M is a drum core, wirewound inductor from Bourns Inc.

  • Shielding: Shielding Feature
  • Tolerance: +/-20%
  • Inductance: 560 nH
  • Maximum Seated Height: 0.232 inches (5.90mm)
  • DC Resistance: 1.5mOhm max
  • Current Rating: 36A
  • Operating Temperature: -55°C to 150°C
  • Package: Nonstandard
  • Dimensions: 0.547 inches L x 0.531 inches W (13.90mm x 13.50mm)
  • Core Material: Iron
  • Frequency Self-Resonant: -
  • Q @ Freq: -
  • Supplied Package: Tape and Reel (TR)
  • Standard Package: 500
