SRP0620-3R3K Real Image
Same model may have multiple batches, images only for reference.

SRP0620-3R3K

Part No SRP0620-3R3K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP0620-3R3K Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0620
Package Tape & Reel
Material - Core Metal
Inductance 3.3 µH
Tolerance ±10%
Current Rating (Amps) 6.6 A
Current - Saturation (Isat) 8.5A
Shielding Shielded
DC Resistance (DCR) 30.2mOhm Max
Q @ Freq 25 @ 7.96MHz
Frequency - Self Resonant 20MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.280" L x 0.264" W (7.10mm x 6.70mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP0620-3R3KDKR,118-SRP0620-3R3KCT,118-SRP0620-3R3KTR
Standard Package 1,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274162-SRP0620-3R3K
Ultra Librarian 3D Model Ultra Librarian SRP0620-3R3K CAD Model

Description

The SRP0620-3R3K is a fixed inductor manufactured by Bourns Inc.

  • Series: SRP0620
  • Core Design: Metal
  • Shielding: Shielded
  • Inductance: 3.3μH
  • Tolerance: ±10%
  • Current: Up to 6.6A
  • DC Resistance: 30.2mΩ max
  • Self-Resonant Frequency: 20MHz
  • Q factor: 25 @ 7.96MHz
  • Temperature Range: -40°C to 125°C
