SRP0312-4R7K Real Image
Same model may have multiple batches, images only for reference.

SRP0312-4R7K

Part No SRP0312-4R7K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0312
Package Tape & Reel
Material - Core Metal
Inductance 4.7 µH
Tolerance ±10%
Current Rating (Amps) 1.9 A
Current - Saturation (Isat) 2.5A
Shielding Shielded
DC Resistance (DCR) 210mOhm Max
Q @ Freq 22 @ 7.96MHz
Frequency - Self Resonant 29MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.134" L x 0.122" W (3.40mm x 3.10mm)
Height - Seated (Max) 0.047" (1.20mm)
Other Names 118-SRP0312-4R7KCT,118-SRP0312-4R7KTR,118-SRP0312-4R7KDKR
Standard Package 4,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274248-SRP0312-4R7K
Ultra Librarian 3D Model Ultra Librarian SRP0312-4R7K CAD Model

Description

The SRP0312-4R7K is a shielded fixed inductor from Bourns Inc. with an inductance of 4.7 µH and a tolerance of ±10%.

  • DC Resistance: 210mOhm max
  • Current Rating: 1.9 A
  • Material - Core: Metal
  • Q @ Freq: 22 @ 7.96MHz
  • Frequency Self-Resonant: 29MHz
  • Packaging: Tape and Reel
  • Height Seated (Max): 0.047" (1.20mm)
  • Dimension: 0.134" L x 0.122" W (3.40mm x 3.10mm)
  • Operating Temperature Range: -40°C ~ 125°C
  • ECCN: EAR99 compliant.
  • MSL Level: 1 (Unlimited) compliant.
