PM42S-470-RC Real Image
Same model may have multiple batches, images only for reference.

PM42S-470-RC

Part No PM42S-470-RC
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description FIXED IND 47UH 620MA 600MOHM SMD / 47 µH Shielded Drum Core, Wirewound Inductor 620 mA 600mOhm Max Nonstandard
Datasheet
PM42S-470-RC Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Manufacturer Bourns Inc.
Packaging Reel - TR
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 47 µH
Tolerance ±30%
Current Rating (Amps) 620 mA
Current - Saturation (Isat) 450mA
Shielding Shielded
DC Resistance (DCR) 600mOhm Max
Q @ Freq 8 @ 2.52MHz
Frequency - Self Resonant 20MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Surface Mount
Case / Package Nonstandard
Size / Dimension 0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max) 0.118" (3.00mm)
Base Product Number PM42S
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Other Part Number PM42S470RC,PM42S-470-RCDKR,PM42S-470-RCTR,PM42S-470-RC-ND,PM42S-470-RCCT
Standard Package 1,000
Win Source Part Number 1328036-PM42S-470-RC
Ultra Librarian 3D Model Ultra Librarian PM42S-470-RC CAD Model

Description

The Bourns Inc. PM42S-470-RC is a fixed inductor that comes with a drum core, wirewound type and shielding.

  • Size/Dimension: 0.189" L x 0.189" W (4.80mm x 4.80mm)
  • Inductance: 47 µH
  • Package: surface mount
  • Tolerance: ±30%
  • Material: ferrite
  • Q @ Freq: 8 @ 2.52MHz
  • Frequency - Self-Resonant: 20MHz
  • DC Resistance (DCR): 600mOhm Max
  • Temperature Range: -40°C ~ 125°C
  • Current Rating (Amps): 620 mA
  • Inductance Frequency-Test: 100 kHz
  • REACH: REACH unaffected
  • HTSUS code: 8504.50.8000
  • ROHS3 compliant: Yes
