The 4816P-1-102LF is a thick film resistor network manufactured by Bourns. This is a SIP (Single In-Line Package) resistor network, commonly utilized for applications such as pull-up resistors, pull-down resistors, current limiting, and voltage dividers. The 'LF' at the end of the part number signifies that this component is lead-free, adhering to RoHS standards.

Applications:

• Pull-up Resistors
• Pull-down Resistors
• Current Limiting
• Voltage Dividers
• Logic circuit termination
• Microcontroller I/O protection

Features:

• SIP (Single In-Line Package): Streamlines PCB layout and reduces component count.
• Thick Film Resistors: Offers good stability and reliability.
• Bussed Resistors: Resistors are connected to a common pin.
• Lead-Free Construction: Compliant with RoHS directive.
• 16 Pins: Provides 16 pins for connection, with 8 resistors connected to a common pin.

Benefits:

• Reduces Component Count: Incorporates multiple resistors into one package, saving board space.
• Simplifies Circuit Design: Simplifies layout particularly in situations where multiple pull-up or pull-down resistors are required.
• Enhances Reliability: Offers improved overall circuit reliability compared to using discrete resistors.
• Cost Effective: Often a more cost-effective solution than using individual resistors.

Additional Details:

The 4816P-1-102LF has a resistance value of 1 kilohm (102 = 10 * 10^2 ohms) per resistor. The '-1' in the part number indicates a common bus configuration, where one pin is connected to all the resistors. Detailed specifications concerning power dissipation, voltage rating, temperature coefficient, and tolerance can be found in the Bourns datasheet for this specific part number. The package style facilitates easy insertion into standard PCB layouts.
