Same model may have multiple batches, images only for reference.
3224W-2-203E Real Image
Same model may have multiple batches, images only for reference.

3224W-2-203E

Part No 3224W-2-203E
Manufacturer Bourns Inc.
Catalog Trimmer Potentiometers
Description TRIMMER 20K OHM 0.25W J LEAD TOP
Datasheet
3224W-2-203E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Potentiometers, Variable Resistors - Trimmer Potentiometers
Mfr Bourns Inc.
Series Trimpot® 3224 - Sealed
Package Tape & Reel
Product Status Active
Resistance 20 kOhms
Power (Watts) 0.25W, 1/4W
Tolerance ±10%
Temperature Coefficient ±100ppm/°C
Number of Turns 12
Adjustment Type Top Adjustment
Resistive Material Cermet
Mounting Type Surface Mount
Termination Style J Lead
Size / Dimension Rectangular - 0.189" x 0.138" Face (4.80mm x 3.50mm)
Base Product Number 3224W
Standard Package 250 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8533.40.8050
California Prop 65 Warning Information
Win Source Part Number 743814-3224W-2-203E
Ultra Librarian 3D Model Ultra Librarian 3224W-2-203E CAD Model

Description

The 743814-3224W-2-203E is a trimmer potentiometer belonging to the Potentiometers, Variable Resistors - Trimmer Potentiometers category.

  • Series: Trimpot® 3224 - Sealed
  • Termination Style: J Lead
  • Potentiometer Type: Rectangular
  • Size: 0.189" x 0.138" face
  • Tolerance: ±10%
  • Temperature Coefficient: ±100ppm/°C
  • Power Rating: 0.25W
  • Adjustment Turns: 12
  • Resistive Material: Cermet
  • Resistance: 20 kOhms
  • Mounting: Surface Mount
  • Manufacturer: Bourns Inc.
  • Status: Active
  • REACH Compliance: Affected
  • California Prop 65: Warning
