BL8506-24CSM BELLING
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer BELLING
Win Source Part Number 235938-BL8506-24CSM
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BL8506-24CSM CAD Model

Description

BL8506-24CSM Voltage Regulator

The BL8506-24CSM is a high-efficiency linear voltage regulator designed for a wide range of electronic applications. It provides a stable 24V output from a variable input voltage, making it an ideal choice for power management.

  • Applications/Projects:
    • Embedded systems
    • Power management in telecommunications
    • Industrial automation equipment
    • Consumer electronics
  • Features and Benefits:
    • High precision output voltage
    • Low dropout voltage
    • Overcurrent and thermal protection
    • Compact SOT-23 package for space-constrained designs
  • Additional Details:
    • Operating temperature: -40°C to +85°C
    • Quiescent current: 50μA (typical)
