DGP12U5D5 Power-One
Same model may have multiple batches, images only for reference.

DGP12U5D5

Part No DGP12U5D5
Manufacturer Bel Power Solutions
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER +/-5V 12W
Datasheet
DGP12U5D5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Bel Power Solutions
Series DGP12 (12W)
Package Bulk
Product Status Obsolete
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 3.5V
Voltage - Input (Max) 16V
Voltage - Output 1 5V
Voltage - Output 2 -5V
Current - Output (Max) 1A, 1A
Power (Watts) 12 W
Voltage - Isolation 700 V
Applications ITE (Commercial)
Features Remote On/Off, SCP
Temperature Range - Operating -50°C ~ 100°C
Efficiency 78%
Mounting Type Through Hole
Package / Case 7-DIP Module
Size / Dimension 2.02" L x 2.02" W x 0.45" H (51.3mm x 51.3mm x 11.4mm)
Control Features Enable, Active High
Standard Package 10 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 584996-DGP12U5D5
Ultra Librarian 3D Model Ultra Librarian DGP12U5D5 CAD Model

Description

The DGP12U5D5 is a high-quality DC-DC converter module from Bel Power Solutions.

  • Series: DGP12 (12W)
  • Module Type: Isolated
  • Output Count: Two
  • Output Voltage: 5V and -5V
  • Power Output: 12W
  • Output Current: 1A (each output)
  • Input Voltage Range: 3.5V to 16V
  • Features: Remote On/Off, Short Circuit Protection (SCP)
  • Size: 2.02" L x 2.02" W x 0.45" H
  • Mounting: Through-Hole
  • Package: Bulk (10 pieces)
