The LP0805A0947AWTR is a multilayer chip inductor manufactured by AVX Corporation. It is designed for high-frequency applications where small size and high performance are critical. This inductor provides excellent electrical characteristics and is suitable for various RF and wireless applications.

Applications

• RF Circuits
• Wireless Communication Devices
• Mobile Phones
• Bluetooth Modules
• GPS Devices
• Matching Networks
• Filter Circuits

Features

• Small Size: 0805 case size (2.0mm x 1.25mm) for compact designs.
• High Self-Resonant Frequency (SRF): Ensures stable performance at high frequencies.
• High Q Factor: Provides low losses and efficient energy storage.
• Tight Tolerance: Offers consistent and reliable performance.
• Multilayer Construction: Enhances inductance and overall performance.
• RoHS Compliant: Environmentally friendly, lead-free construction.

Benefits

• Miniaturization: Enables smaller and more compact electronic devices.
• Improved Performance: High Q factor and SRF ensure efficient operation in RF circuits.
• Reliability: Tight tolerance and robust construction provide consistent performance.
• Easy Integration: Surface mount design simplifies assembly and integration.

Technical Specifications

Key specifications of the LP0805A0947AWTR typically include:

• Inductance: 94.7 nH
• Tolerance: Consult datasheet for specific tolerance (e.g., ±3%)
• Self-Resonant Frequency (SRF): Specified in MHz (check datasheet for value)
• Q Factor: Specified at a given frequency (check datasheet for value)
• DC Resistance (DCR): Low DCR for minimal power loss
• Operating Temperature Range: Typically -55°C to +125°C
• Case Size: 0805 (2.0mm x 1.25mm)
