PGH50N16 NIHON DEMPA KOGYO
Same model may have multiple batches, images only for reference.

PGH50N16

Part No PGH50N16
Manufacturer AVX Corp/Kyocera Corp
Catalog TVS - Thyristors
Description THYRISTOR MODULE 3PHASE LEG T+D
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Thyristors - SCRs - Modules
Mfr AVX Corp/Kyocera Corp
Package Bulk
Product Status Active
Structure Bridge, 3-Phase - SCRs/Diodes
Number of SCRs, Diodes 1 SCR, 6 Diodes
Voltage - Off State 1.6 kV
Current - On State (It (AV)) (Max) 50 A
Voltage - Gate Trigger (Vgt) (Max) 2.5 V
Current - Gate Trigger (Igt) (Max) 100 mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 1200A @ 50Hz
Current - Hold (Ih) (Max) 80 mA
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Chassis Mount
Package / Case Module
Standard Package 100 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8541.30.0080
Win Source Part Number 654489-PGH50N16
Ultra Librarian 3D Model Ultra Librarian PGH50N16 CAD Model

Description

The 654489-PGH50N16 is a thyristor SCR module from AVX Corp/Kyocera Corp.

  • Category: Discrete semiconductor products - thyristors - SCRs - modules
  • Application: Bridge, 3-phase
  • Configuration: 1 SCR and 6 diodes
  • Package: Bulk
  • Standard Package: 100 pieces
  • Maximum Current Hold: 80mA
  • Off-State Voltage: 1.6kV
  • Maximum Gate Trigger Voltage: 2.5V
  • Maximum Gate Trigger Current: 100mA
  • Maximum On-State Current: 50A
  • Non-Repetitive Surge Current: 1200A @ 50Hz
  • Mounting Type: Chassis mount
  • Temperature Range: -40°C to 150°C
