NSQ03A04 Nihon Inter Electronics Corporation
Same model may have multiple batches, images only for reference.

NSQ03A04

Part No NSQ03A04
Manufacturer AVX Corp/Kyocera Corp
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 3A NSMC
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr AVX Corp/Kyocera Corp
Package Tape & Reel
Product Status Obsolete
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 40 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 550 mV @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 3 mA @ 40 V
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package nSMC
Operating Temperature - Junction -40°C ~ 150°C
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 259873-NSQ03A04
Ultra Librarian 3D Model Ultra Librarian NSQ03A04 CAD Model

Description

The 259873-NSQ03A04 is a fast recovery Schottky diode from AVX Corp/Kyocera Corp.

  • Type: Single Diode
  • Category: Discrete Semiconductor Products - Diodes - Rectifiers
  • Package: Tape & Reel
  • Standard Package: 3,000 pieces
  • Maximum Reverse Voltage Rating: 40V
  • Average Rectified Current: 3A
  • Speed: Less than 500ns
  • Forward Voltage Drop: 550mV @ 3A
  • Mounting Type: Surface Mountable
  • Package: DO-214AB, SMC
  • Status: Obsolete
  • Description: Although it is currently obsolete, it can still be used in various electronic circuits and systems that require fast rectification and low forward voltage drop.
