AK8158A Asahi Kasei Microsystems
Same model may have multiple batches, images only for reference.

AK8158A

Part No AK8158A
Manufacturer Asahi Kasei Microsystems
Catalog Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description IC CLOCK GENERATOR 20QFN
Datasheet
AK8158A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Mfr Asahi Kasei Microsystems
Package Tape & Reel
Product Status Obsolete
Programmable Not Verified
Type Clock Generator, VCXO
PLL Yes
Input Crystal
Output Clock
Number of Circuits 3
Frequency - Max 27MHz
Divider/Multiplier Yes/No
Voltage - Supply 2.85V ~ 3.6V
Temperature Range - Operating -20°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 20-WFQFN Exposed Pad
Supplier Device Package 20-QFN (4x4)
Standard Package 1,000 pcs
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 560599-AK8158A
Ultra Librarian 3D Model Ultra Librarian AK8158A CAD Model

Description

The AK8158A is an obsolete clock generator and VCXO integrated circuit (IC) from Asahi Kasei Microsystems.

  • Category: Clock/Timing - Clock Generators, PLLs, and Frequency Synthesizers
  • Packaging: Tape & reel
  • Maximum Frequency: 27MHz
  • Circuits: 3
  • Standard Package: 1,000 pieces
  • Voltage Supply: 2.85V to 3.6V
  • Mounting Type: Surface Mount
  • Package: 20-WFQFN exposed pad
  • Status: Obsolete
  • ECCN: EAR99
  • Manufacturer: Asahi Kasei Microsystems
