Same model may have multiple batches, images only for reference.

BXA10-48D05J

Get a Quote

Part No	BXA10-48D05J
Manufacturer	Artesyn Embedded Technologies
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-5V 10W
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Artesyn Embedded Technologies
Series	BXA10 (10W)
Package	Bulk
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	18V
Voltage - Input (Max)	75V
Voltage - Output 1	5V
Voltage - Output 2	-5V
Current - Output (Max)	1A, 1A
Power (Watts)	10 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	OVP, SCP
Temperature Range - Operating	-25°C ~ 71°C
Efficiency	82%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Size / Dimension	2.00" L x 1.00" W x 0.42" H (50.8mm x 25.4mm x 10.5mm)
Standard Package	50 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	573844-BXA10-48D05J
Ultra Librarian 3D Model	Ultra Librarian BXA10-48D05J CAD Model

Alternative Products

Description

The BXA10 (10W) is an isolated module power supply suitable for board mount applications from Artesyn Embedded Technologies.

Features: OVP (Over Voltage Protection) and SCP (Short Circuit Protection)
Size: 2.00" L x 1.00" W x 0.42" H
Power Rating: 10W
Isolation Voltage: 1.5 kV
Outputs: 5V and -5V
Efficiency: 82%
Operating Temperature: -25°C ~ 71°C
Mounting: through-hole
Package: 6-DIP module
