Analog Devices Inc. LTC4359HMS8#PBF

The LTC4359HMS8#PBF is a high-performance, long-lasting ideal diode controller from Analog Devices Inc., designed to replace power Schottky diodes in a variety of applications. This advanced component ensures low power loss and heat dissipation by controlling an external N-channel MOSFET to emulate a near-zero voltage drop diode.

Key Features

• Low Loss Replacement for Schottky Diodes: The LTC4359HMS8#PBF effectively replaces power Schottky diodes, minimizing voltage drop and power loss across the diode.
• Wide Operating Voltage Range: This device is versatile with a wide operating voltage range of 9V to 80V, catering to a broad spectrum of power systems.
• Reverse Input Protection to -40V: It provides robust protection against reverse input voltages up to -40V, ensuring the safety and longevity of the connected components.
• Smooth Switchover: The LTC4359HMS8#PBF facilitates seamless switchover between power sources without oscillation, which is critical for systems requiring uninterrupted power.
• No Reverse DC Current: The device prevents reverse DC current, protecting downstream components from potential damage.
• Adjustable Turn-On Speed: The turn-on speed is adjustable, allowing for flexible integration into various systems with different requirements.

Applications

The LTC4359HMS8#PBF is an ideal choice for a wide range of applications, including:

• Automotive power systems
• Redundant power supplies
• High power density systems
• Or-ing diodes in N+1 redundant power systems
• Solar power applications with multiple panel strings

Package and Quality

Encased in an MSOP-8 package, the LTC4359HMS8#PBF is compact and suitable for space-constrained applications. Analog Devices Inc. ensures the highest quality and reliability, making this component a reliable choice for critical systems where performance and durability are paramount.
