The AD5766BCBZ-RL7, manufactured by Analog Devices Inc., is a high-precision, 16-channel, 16-bit digital-to-analog converter (DAC) that offers a compact and efficient solution for advanced industrial control systems, automated test equipment, and precision instrumentation applications.

Key Features

• Resolution: The AD5766BCBZ-RL7 boasts a 16-bit resolution, providing fine-grain control over output signals.
• Channels: With 16 independent channels, this DAC can manage multiple output tasks simultaneously, making it ideal for complex systems that require multiple analog outputs.
• Output Range: It features a versatile output range that includes bipolar and unipolar options, which can be programmed through a serial interface.
• Integrated Reference: The inclusion of an on-chip 2.5V reference voltage simplifies the design by reducing the need for external components.
• Package: The device is housed in a compact 48-lead LFCSP (7mm x 7mm) package, allowing for a reduced footprint on printed circuit boards.
• Interface: It supports a 3-wire serial interface that is compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards, providing versatility in system design.

Applications

The AD5766BCBZ-RL7 is designed to meet the demands of a range of applications where precision and channel density are critical. It is particularly well-suited for:

• Industrial Automation
• Process Control
• Data Acquisition Systems
• Digital Gain and Offset Adjustment
• Programmable Voltage and Current Sources

Performance and Quality

Analog Devices Inc. is renowned for its commitment to high-quality and performance. The AD5766BCBZ-RL7 is no exception, with its robust design ensuring stable and reliable performance even in the most demanding environments. The device operates over a wide temperature range and has built-in thermal protection to maintain accuracy and protect against overheating.

Ordering Information

The AD5766BCBZ-RL7 is available for order in reel form, facilitating its integration into automated manufacturing processes. For detailed specifications and ordering information, customers can visit the Analog Devices Inc. website or contact their sales representatives.
