The ADUM2402ARWZ is a state-of-the-art digital isolator manufactured by Analog Devices Inc., designed to provide reliable signal isolation in various industrial and commercial applications. This robust component is part of the ADuM240x series, which utilizes Analog Devices' patented iCoupler® technology to achieve magnetic and capacitive isolation within a small form factor.

Key Features

• Channels: The device comes with four independent isolation channels arranged in a bidirectional configuration, providing versatility in interfacing between different domains.
• Data Rate: It supports a high data rate of up to 25 Mbps, ensuring fast and efficient data communication for critical applications.
• Isolation Voltage: Offers an impressive isolation voltage rating of 2500 Vrms for 1 minute, which ensures reliable operation in environments with high voltage differentials.
• Integration: The ADUM2402ARWZ integrates a series of features such as thermal shutdown and low power operation, enhancing its safety and energy efficiency.
• Package: Housed in a 16-lead SOIC wide body package, the device is compact and suitable for space-constrained applications, while also providing a creepage and clearance distance that meets stringent safety requirements.

Applications

The digital isolator is ideal for a range of applications, including:

• Industrial field networks
• Isolated SPI interfaces
• General-purpose multichannel isolation
• Isolated RS-232/RS-422/RS-485 interfaces
• Industrial PLCs

Reliability and Compliance

The ADUM2402ARWZ is designed with reliability in mind and complies with several industry standards, including UL, CSA, VDE, and CQC certifications, ensuring it meets global safety and regulatory requirements. Its high-performance characteristics make it an excellent choice for designers looking to enhance system reliability and performance while maintaining compliance with safety standards.
