ADM2687EBRIZ: A Robust Isolated RS-485 Transceiver from Analog Devices Inc.

The ADM2687EBRIZ is a state-of-the-art, integrated signal and power isolated data transceiver with ±15 kV ESD protection, designed to operate in harsh industrial environments. Manufactured by Analog Devices Inc., a leader in high-performance semiconductors, this device offers a reliable solution for bidirectional communication on RS-485 or RS-422 networks.

Key Features:

• Integrated Isolation: The ADM2687EBRIZ features Analog Devices' iCoupler® technology, providing 5 kVrms signal and power isolation, which protects the system from surges and ground loops, ensuring data integrity and reducing system failures.
• High Data Rates: Capable of supporting data rates up to 16 Mbps, this transceiver is well-suited for high-speed data communication in industrial applications.
• Robust ESD Protection: It comes with an industry-leading ±15 kV ESD protection on the RS-485 input/output pins, safeguarding the device from electrostatic discharges that could occur during installation or operation.
• Thermal Shutdown Protection: The transceiver includes a thermal shutdown feature that prevents damage from overheating, further enhancing the reliability of the device.
• Wide Operating Temperature Range: Designed to function in extreme conditions, the ADM2687EBRIZ operates within a temperature range of -40°C to +85°C, making it suitable for industrial environments.
• Reduced Footprint: Offered in a compact, surface-mountable SOIC package, the device minimizes board space and simplifies PCB design.
• Half-Duplex Communication: The device supports half-duplex communication, allowing for two-way communication over a single pair of wires, simplifying network topology.

Applications:

The ADM2687EBRIZ is ideal for a variety of applications that require robust communication with isolation, such as:

• Industrial control and automation
• Building automation
• Factory automation networks
• Motor control systems

With its integrated approach to signal and power isolation, the ADM2687EBRIZ provides a compact and efficient solution for designers looking to enhance the reliability and performance of their RS-485/RS-422 communication systems. Analog Devices Inc.'s commitment to quality ensures that this transceiver meets the highest standards for industrial communication applications.
