Product Overview: ADG758BCPZ-REEL from Analog Devices Inc.

The ADG758BCPZ-REEL is a high-performance CMOS analog multiplexer from Analog Devices Inc., a leading innovator in the semiconductor industry. This particular device is part of the REEL packaging series, which indicates that it is provided in tape and reel packaging suitable for automated assembly processes. The ADG758 is designed for precision, low-voltage data acquisition systems and offers a robust feature set that makes it ideal for a variety of applications.

Key Features

• Low On Resistance: The ADG758 features a low on resistance (Ron) of typically 4.5 ohms, which provides a minimal signal attenuation, ensuring high signal integrity.
• Single Supply Operation: It operates from a single 1.8V to 5.5V power supply, making it versatile for both portable and stationary applications.
• 3.3 V Logic Compatible Inputs: The inputs are compatible with 3.3V logic levels, even when operated on 5V supplies, which allows for easy interfacing with modern microcontrollers and digital logic.
• Low Power Consumption: The ADG758 offers low power consumption, which is critical for battery-powered devices, ensuring longer operation times.
• High Throughput: With a fast switching time and a low charge injection, this multiplexer is capable of high-throughput applications.

Applications

The ADG758BCPZ-REEL is suitable for a wide range of applications, including:

• Data acquisition systems
• Battery-powered systems
• Sample-and-hold systems
• Audio and video signal routing
• Industrial control systems
• Communication systems
• Automotive systems

Its compact LFCSP (Lead Frame Chip Scale Package) ensures a minimal footprint on the PCB, which is essential for space-constrained designs. The device also boasts excellent thermal performance and reliability, thanks to Analog Devices' rigorous quality control and advanced manufacturing techniques.

Analog Devices Inc. is known for their precision engineering and the ADG758BCPZ-REEL is no exception. It represents a blend of performance, power efficiency, and design flexibility, making it a top choice for engineers and designers looking to enhance their systems with a reliable multiplexing solution.
