Product Overview: ADG749BKSZ-REEL

The ADG749BKSZ-REEL is a high-performance, CMOS analog switch manufactured by Analog Devices Inc., renowned for its precision in signal processing technology. This particular component is part of the ADG749 series, which is designed to provide efficient solutions for routing analog signals in a wide range of applications, including communication systems, data acquisition, and audio/video signal routing.

Key Features

• Low On Resistance: The ADG749BKSZ-REEL boasts a low on resistance (Ron) typically around 0.4 ohms, ensuring minimal signal distortion and power loss when the switch is closed.
• Single Supply Operation: This switch operates from a single 1.8 V to 5.5 V power supply, making it versatile for various applications and simplifying power management within a system.
• 1.65 V Logic Compatible: The device is compatible with 1.65 V logic inputs, allowing it to interface with low-voltage digital controllers and processors.
• Low Power Consumption: With its CMOS construction, the ADG749BKSZ-REEL consumes very low power, which is crucial for battery-powered and energy-sensitive applications.
• Fast Switching Times: It features fast switching times (tON and tOFF) in the nanosecond range, providing quick response times necessary for high-speed signal routing.
• Wide Operating Temperature Range: The switch can operate over an extended temperature range, making it suitable for industrial environments.

Package and Quality

The ADG749BKSZ-REEL comes in a compact 6-lead SC70 package, which is ideal for space-constrained applications. It is provided in tape and reel form, facilitating efficient handling and manufacturing processes. Analog Devices Inc. ensures high-quality and reliability standards, making the ADG749BKSZ-REEL a trustworthy choice for critical applications.

Applications

Due to its versatility and high performance, the ADG749BKSZ-REEL is well-suited for a variety of applications, including:

• Audio and video signal routing
• Data acquisition systems
• Communication systems
• Sample and hold circuits
• Portable battery-powered devices
• Test equipment and instrumentation

With its robust feature set and the backing of Analog Devices' expertise, the ADG749BKSZ-REEL is an excellent choice for designers looking to implement a reliable analog switching solution in their next project.
