Analog Devices Inc. ADG723BRMZ

The ADG723BRMZ is a high-performance, CMOS analog switch developed by Analog Devices Inc., a renowned leader in precision high-performance integrated circuits. This product is part of the ADG72x series, which is characterized by its low on-resistance and low power consumption, making it an ideal choice for a variety of applications where efficient power usage and signal integrity are of paramount importance.

Designed to operate with a single 1.8 V to 5.5 V power supply, the ADG723BRMZ offers versatility in its application, allowing it to be used in systems with varying power levels. This feature also enables the switch to be compatible with a wide range of other logic families, enhancing its adaptability in mixed-voltage systems.

Featuring a dual single-pole, double-throw (SPDT) switch configuration, the ADG723BRMZ provides the flexibility needed for routing and multiplexing analog signals. Its low on-resistance (typically 4 ohms) ensures minimal signal distortion, while the on-resistance flatness maintains signal fidelity across the entire analog input range, making it an excellent choice for precision applications.

The switch's fast switching times (t_ON and t_OFF) of typically 20 ns and 10 ns respectively, enable quick signal routing, which is essential for applications requiring high-speed operation. Furthermore, the ADG723BRMZ exhibits a low charge injection, which minimizes the impact on the signal during the switching process, thus preserving the integrity of the analog signal.

For enhanced robustness, the ADG723BRMZ offers built-in overvoltage protection, ensuring that the device is safeguarded against unexpected voltage spikes that could potentially damage the IC. Additionally, the device comes in a compact 10-lead MSOP (Mini Small Outline Package) that is suitable for space-constrained applications.

With its combination of low power consumption, high switching speed, and precision performance, the ADG723BRMZ from Analog Devices Inc. is an excellent choice for designers looking to incorporate a reliable and efficient analog switch into their systems. Applications include data acquisition systems, communication systems, audio and video signal routing, and any other application that requires high-performance analog signal management.
