ADG712BRUZ - CMOS Low Voltage 4 Channel Multiplexer

The ADG712BRUZ is a monolithic CMOS device comprising four independently selectable single-pole, double-throw (SPDT) switches. This versatile component is manufactured by Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits.

Key Features

• Low Voltage Operation: The device operates from a single 1.8 V to 5.5 V power supply, making it suitable for battery-powered and portable applications.
• Low On Resistance: With a typical on resistance of just 4 ohms, the ADG712BRUZ ensures minimal signal distortion and power loss.
• High Throughput: It features a fast switching action with t_ON of 30 ns and t_OFF of 20 ns, enabling efficient signal routing.
• Low Power Consumption: The device boasts a low power consumption with a typical ICQ of only 1 µA, making it ideal for power-sensitive applications.

Applications

The ADG712BRUZ is well-suited for a variety of applications, such as:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Relay replacement
• Battery-powered systems

Package and Quality

The device is offered in a compact 16-lead TSSOP (Thin Shrink Small Outline Package) package, designated by the suffix 'RUZ'. This package is designed for space-saving on the PCB without compromising performance. Additionally, the ADG712BRUZ is part of Analog Devices Inc.'s commitment to high-quality products, and it is RoHS compliant, ensuring adherence to environmental standards and regulations.

Conclusion

With its combination of low voltage operation, low power consumption, and high-speed performance, the ADG712BRUZ from Analog Devices Inc. is an excellent choice for designers looking to implement efficient and reliable signal switching in their electronic systems. Its robust design and small footprint make it a versatile component for a wide range of applications.
