Product Overview: ADG708BRUZ-REEL

The ADG708BRUZ-REEL is a high-performance, low-voltage 4-channel multiplexer from Analog Devices Inc., designed for precision data acquisition and control systems. This CMOS analog multiplexer offers a single-ended 8-to-1 multiplexing configuration, allowing users to select one of eight inputs to be passed to the output.

Key Features

• Low On Resistance: The ADG708 features a low on resistance (typically 4 ohms), which minimizes signal attenuation and ensures excellent linearity and low insertion loss.
• Single Supply Operation: It operates from a single 1.8V to 5.5V power supply, making it suitable for portable and battery-powered applications.
• Low Power Consumption: This device has a very low power consumption, with a typical supply current of less than 0.1µA, ideal for power-sensitive applications.
• High Throughput Rate: With a fast switching speed and a bandwidth of over 100MHz, the ADG708BRUZ-REEL is capable of handling high-speed signals without significant distortion.
• Digital Control: Digital selection of the desired channel is provided via a 3-wire serial interface, which is compatible with standard SPI, QSPI™, MICROWIRE™, and DSP interface standards.
• Break-Before-Make Switching: This feature ensures that no two channels are connected simultaneously, preventing signal overlap and preserving the integrity of the data.
• Extended Temperature Range: The device is specified for the extended industrial temperature range of -40°C to +85°C, suitable for harsh operating environments.

Applications

The ADG708BRUZ-REEL is versatile and can be used in a variety of applications, including:

• Data acquisition systems
• Battery-powered systems
• Sample-and-hold systems
• Audio and video signal routing
• Communication systems
• Automotive systems

With its compact surface-mount package (TSSOP), the ADG708BRUZ-REEL is designed for space-constrained applications. The REEL designation indicates that this product is available in tape and reel packaging, facilitating efficient handling and manufacturing processes, especially suited for high-volume production environments.

Overall, the ADG708BRUZ-REEL from Analog Devices Inc. is a reliable and precise solution for designers looking to integrate an efficient multiplexing function into their systems with minimal power draw and high performance.
