Product Overview: ADG5204BRUZ-RL7

The ADG5204BRUZ-RL7 is a high-performance, 4-channel analog multiplexer from Analog Devices Inc., a leading global manufacturer of precision high-performance integrated circuits used in analog and digital signal processing applications. This particular device is part of the robust ADG5204 series, known for its reliability and versatility in various applications.

Key Features

• High Voltage Tolerance: The ADG5204BRUZ-RL7 operates with a dual power supply ranging from ±10.8 V to ±16.5 V or a single supply from 10.8 V to 33 V, providing design flexibility for various system requirements.
• Low Charge Injection: With its low charge injection feature, this multiplexer ensures that minimal charge is transferred during switching, making it ideal for precision applications.
• Low On Resistance: The device boasts a low on resistance (R<sub>ON) that typically remains flat over the full analog input range, ensuring excellent linearity and minimal signal attenuation.
• High Off Isolation: High off isolation prevents signal leakage between channels when they are not in use, maintaining signal integrity and reducing noise.
• Latch-Up Proof: Built with a latch-up proof design, the ADG5204BRUZ-RL7 is immune to latch-up, enhancing the robustness of the device in complex electronic systems.

Applications

The ADG5204BRUZ-RL7 is suitable for various applications, such as data acquisition systems, industrial automation, battery-powered systems, and audio and video routing. Its high performance and reliability make it a preferred choice for designers who require a multiplexer that can handle high voltage levels while maintaining signal fidelity.

Package and Quality

This specific model, the ADG5204BRUZ-RL7, comes in a TSSOP (Thin Shrink Small Outline Package) with 16 leads, offering a compact footprint for space-constrained applications. It is available in a reel format (RL7), facilitating efficient assembly for high-volume production. Analog Devices Inc. ensures that this product meets stringent quality standards, providing reliable performance for critical applications.

Ordering Information

For detailed ordering and shipping information, customers can refer to the Analog Devices Inc. website or contact their local sales office. The part number ADG5204BRUZ-RL7 should be used when placing orders to ensure the correct product is received.
