Product Overview

The ADG467BRZ-REEL7 is a robust, high-performance channel protector from Analog Devices Inc., designed to safeguard sensitive analog inputs from overvoltage conditions that can arise in harsh industrial environments. This component is a part of the REEL7 packaging series, indicating that it is provided in a tape and reel format suitable for automated assembly processes.

Key Features

• Channels: The ADG467BRZ-REEL7 features seven independent channels, each capable of protecting analog inputs.
• Overvoltage Protection: It offers excellent overvoltage protection up to ±17 volts, ensuring the safety of the connected circuitry even under extreme conditions.
• Low On Resistance: With a low on resistance typically around 7 ohms, it ensures minimal signal attenuation and distortion, maintaining signal integrity.
• Low Leakage Current: The device exhibits low leakage current, which is critical for maintaining accuracy in precision analog applications.
• Supply Voltage Range: The ADG467BRZ-REEL7 operates on a single 12 V to 30 V supply, or a dual ±12 V to ±15 V supply, providing flexibility in various system designs.
• Power-On Protection: Inputs and outputs of the ADG467BRZ-REEL7 are protected during power-off conditions, enhancing the reliability of the system.
• Package: The component is offered in a compact 16-lead SOIC (Small Outline Integrated Circuit) package, which is space-efficient and ideal for densely packed PCBs.

Applications

The ADG467BRZ-REEL7 is suitable for a wide range of applications where input channel protection is paramount. These include:

• Industrial control systems
• Data acquisition systems
• Process control interfaces
• Instrumentation
• Medical equipment

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability, and the ADG467BRZ-REEL7 is no exception. It is manufactured to the highest standards, ensuring consistent performance and durability in various operating conditions. With its robust protection features and flexible supply voltage range, this channel protector is an excellent choice for designers looking to enhance the resilience of their electronic systems.
