ADG1636BRUZ Dual SPDT Switch by Analog Devices Inc.

The ADG1636BRUZ is a robust, high-performance dual single-pole/double-throw (SPDT) switch from Analog Devices Inc., designed for bidirectional data flow in various applications. Engineered with precision and durability in mind, this component is a perfect fit for systems that require reliable switching operations.

Key Product Features:

• Low On-Resistance: The ADG1636BRUZ boasts an exceptionally low on-resistance (Ron) of typically 0.5 ohms, which minimizes signal distortion and ensures efficient signal transmission.
• Wide Voltage Range: It operates over a wide single-supply voltage range of 1.8 V to 5.5 V or dual supplies of ±2.5 V, providing flexibility for various circuit configurations.
• High Current Carrying Capacity: With a continuous current rating of up to 300 mA per channel, this switch can handle significant current without performance degradation.
• 3.3 V/5 V Logic Compatibility: The switch logic control inputs are compatible with 3.3 V or 5 V logic levels, making it easy to interface with a wide range of microcontrollers and logic devices.
• ESD Protection: Enhanced electrostatic discharge (ESD) protection is built-in, safeguarding the device against unexpected voltage spikes.
• Automotive Qualification: The ADG1636BRUZ is qualified for automotive applications, ensuring reliability and performance under harsh conditions.

Applications:

The versatility of the ADG1636BRUZ allows it to be used in a variety of applications, including but not limited to:

• Audio and video signal routing
• Communication systems
• Data acquisition systems
• Relay replacement
• Battery-powered systems

Product Specifications:

Parameter Value Package TSSOP-14 Temperature Range -40°C to +125°C On-Time (t<sub>ON) 20 ns (Typical) Off-Time (t<sub>OFF) 30 ns (Typical)

For more detailed information, refer to the ADG1636BRUZ datasheet.
