ADG1608BRUZ-REEL7

Part No ADG1608BRUZ-REEL7
Manufacturer Analog Devices Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description 4.5 Ω RON, 4-/8-Channel ±5 V,+12 V, +5 V, and +3.3 V Multiplexers
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Number of Circuits 1
On-State Resistance (Maximum) 4.5 Ohm
Channel-to-Channel Matching (ΔRon) 120 mOhm
Operating Supply Voltage 3.3 V ~ 16 V
Dual Voltage Supply ±3.3 V ~ 8 V
Switch Time (Ton, Toff) (Maximum) 94ns, 93ns
-3db Bandwidth 40MHz
Charge Injection 29pC
Channel Capacitance (CS(off), CD(off)) 19pF, 117pF
Current - Leakage (IS(off)) (Maximum) 100pA
Crosstalk -64dB @ 1MHz
Operating Temperature Range -40°C ~ 125°C (TA)
Package 16-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 16-TSSOP
Win Source Part Number 1140135-ADG1608BRUZ-REEL7
Manufacturer Homepage www.analog.com
Family Name ADG1608
Introduction Date July 31, 2009
ECCN EAR99
Country of Origin Taiwan
Halogen Free Not Compliant
Estimated EOL Date 2028
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ADG1608BRUZ-REEL7 CAD Model

Description

ADG1608BRUZ-REEL7: High-Performance Analog Multiplexer

The ADG1608BRUZ-REEL7 is a versatile and high-performance analog multiplexer from the renowned manufacturer Analog Devices Inc. This component is part of the expansive ADG1608 series, known for its reliability and precision in a variety of electronic applications. The device is designed to operate with a single 3.3 V to 5 V power supply, making it suitable for many modern low-voltage systems.

The ADG1608BRUZ-REEL7 features eight single channels and comes in a compact TSSOP (Thin Shrink Small Outline Package) form factor, which is ideal for space-constrained applications. It offers a bidirectional signal path, which allows for versatile routing of analog signals. The multiplexer's on-resistance is typically low, and it flaunts a flatness that ensures signal integrity is maintained across its entire operating range.

One of the key advantages of the ADG1608BRUZ-REEL7 is its fault protection. When the device is powered off, the inputs and outputs have overvoltage protection up to ±16 V, which significantly enhances the robustness of the system it is integrated into. Additionally, the device has a built-in break-before-make switching mechanism, which prevents momentary shorting when switching channels. This is critical for applications where signal integrity is paramount.

The multiplexer's digital inputs are TTL and CMOS compatible, making it easy to interface with a wide range of logic controllers and microprocessors. The ADG1608BRUZ-REEL7 is provided in tape and reel form, making it suitable for automated assembly processes, which is indicated by the 'REEL7' suffix in the product name.

Applications for the ADG1608BRUZ-REEL7 are diverse and include data acquisition systems, communication systems, ATE (automatic test equipment), and any application where routing multiple analog signals through a single channel is necessary. With its excellent performance characteristics and reliability, the ADG1608BRUZ-REEL7 is a solid choice for designers looking for a high-quality analog multiplexer solution.

Overall, the ADG1608BRUZ-REEL7 from Analog Devices Inc. is a testament to the company's commitment to providing high-performance, reliable components for the electronics industry. Its integration into a system promises to enhance performance while ensuring signal integrity and protection.
