Product Overview: AD9984AKSTZ-170

The AD9984AKSTZ-170 is a high-performance, mixed-signal front-end (MxFE) integrated circuit designed by Analog Devices Inc., a renowned leader in the semiconductor industry. This advanced component is specifically engineered for video and graphics applications that demand high-quality image acquisition and processing.

Key Features

• Resolution: The AD9984AKSTZ-170 supports resolutions up to UXGA (1600x1200) at 170 MHz, making it ideal for high-resolution displays and advanced imaging systems.
• Color Depth: It offers a color depth of up to 10 bits per channel, providing a broad spectrum of colors and ensuring that images are rendered with precision and clarity.
• Interface: The device includes a high-speed triple analog-to-digital converter (ADC) with integrated clamps and a phase-locked loop (PLL) to ensure stable and accurate signal conversion and synchronization.
• Low Power Consumption: Designed with power efficiency in mind, the AD9984AKSTZ-170 maintains high performance while minimizing power usage, making it suitable for energy-sensitive applications.
• Package: Housed in a compact 100-lead LQFP (Low-profile Quad Flat Package), the product is designed for space-constrained environments without compromising on functionality.
• Flexibility: The versatile input range and programmable gain and offset adjustments make this device adaptable to a wide variety of signal types and sources.

Applications

The AD9984AKSTZ-170 is widely used in various high-end video and graphic systems, including:

• Professional video editing and broadcasting equipment
• Advanced computer monitors and projectors
• Medical imaging devices
• Industrial imaging and inspection systems

Technical Support and Quality Assurance

Analog Devices Inc. provides comprehensive technical support for the AD9984AKSTZ-170, including detailed datasheets, application notes, and reference designs to facilitate system integration. Quality is ensured through rigorous testing and adherence to industry standards, making this product a reliable choice for designers and engineers seeking to incorporate high-quality video processing capabilities into their applications.
