AD7841ASZ-REEL Analog Devices Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

AD7841ASZ-REEL

Part No AD7841ASZ-REEL
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description IC DAC 14BIT V-OUT 44MQFP
Datasheet
AD7841ASZ-REEL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Bits 14
Number of D/A Converters 8
Settling Time 31µs (Typ)
Output Type Voltage - Buffered
Differential Output No
Data Interface Parallel
Reference Type External
Voltage - Supply, Analog ±13.5V ~ 16.5V
Voltage - Supply, Digital 5V
INL/DNL (LSB) ±4 (Max), -0.9/+2 (Max)
Architecture R-2R
Temperature Range - Operating -40°C ~ 85°C
Case / Package 44-QFP
Supplier Device Package 44-MQFP (10x10)
Mounting Type Surface Mount
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1496939-AD7841ASZ-REEL
Ultra Librarian 3D Model Ultra Librarian AD7841ASZ-REEL CAD Model
