Product Overview: AD780ARZ-REEL7 - Analog Devices Inc.

The AD780ARZ-REEL7 is a high-precision, low-power voltage reference from Analog Devices Inc., renowned for its stability and accuracy in critical applications. This component is part of a series that is designed to provide a precise 2.5V or 3.0V output from a wide input voltage range. It is commonly used in high-end instrumentation, A/D and D/A converters, and precision measurement devices.

Key Features:

• Output Voltage: Selectable 2.5V or 3.0V with high accuracy.
• Initial Accuracy: ±0.1% max.
• Temperature Coefficient: 10 ppm/°C max over the industrial temperature range.
• Low Noise: Offers a low, 1.0 μV p-p (0.1 Hz to 10 Hz) noise performance.
• Low Dropout Voltage: Typically 200 mV at 10 mA load.
• Output Current: High output current capability, up to 10 mA source and sink.
• Long-Term Stability: Excellent long-term stability and low hysteresis.
• Package: Available in a small surface-mount package, specifically in a 3-lead SOT-23.
• Supply Range: Wide supply voltage range from 4.0 V to 36 V, or ±2.0 V to ±18 V.
• Temperature Range: Operates over a -40°C to +85°C temperature range.

Applications:

• Precision data acquisition systems.
• High-resolution converters.
• Industrial process control systems.
• Battery-powered and portable equipment.
• Optical network control systems.

The AD780ARZ-REEL7 is supplied in a tape and reel format, which is ideal for automated assembly processes. This voltage reference is a versatile solution for designers seeking a reliable, high-performance component that maintains its precision across a range of operating conditions. With its robust design and exceptional performance, the AD780ARZ-REEL7 is a valuable addition to any precision electronic system.
