The AD592ANZ is a high-precision integrated circuit temperature transducer from Analog Devices Inc. that provides an output current proportional to absolute temperature. This innovative product is designed for superior temperature sensing with a linear temperature-to-current conversion characteristic. The AD592ANZ is an ideal solution for applications requiring precise temperature measurements and control, ranging from environmental control systems to process control and medical applications.

Key Features

• Temperature Range: The device is operational over a temperature range of -25°C to +105°C, making it versatile for diverse applications.
• High Accuracy: It features a high level of accuracy, with a temperature error of less than ±0.5°C after calibration.
• Linear Output: The output current ranges from 1 µA/K at -25°C to 1 mA/K at 105°C, providing a direct and linear relationship between the temperature and the output current.
• Calibration: The AD592ANZ can be easily calibrated with a single external resistor or by adjusting the supply current.
• Supply Voltage: It operates from a wide supply voltage range of 4 V to 30 V, accommodating various system designs and power supplies.
• Low Power Consumption: The device consumes a low quiescent current, making it suitable for battery-powered applications.
• Package: It is offered in a compact TO-92 package, which is convenient for PCB mounting and space-constrained applications.

Applications

The AD592ANZ is a versatile component that can be integrated into a wide range of temperature monitoring systems. Its applications include:

• Temperature control systems and thermostats
• Industrial process control and instrumentation
• Data acquisition systems
• Medical and healthcare equipment
• Environmental monitoring
• Automotive temperature sensing
• Energy management

With its high precision and ease of use, the AD592ANZ from Analog Devices Inc. is an excellent choice for designers and engineers looking for a reliable temperature sensing solution. Its robust design ensures consistent performance and durability, even in challenging environmental conditions.
