AD5272BRMZ-50 Digital Potentiometer by Analog Devices Inc.

The AD5272BRMZ-50, manufactured by Analog Devices Inc., is a precision digital potentiometer that offers a compact and high-performance solution for a wide range of applications. This device is part of the AD5272 series, renowned for their reliability and versatility in various electronic systems.

Key Features:

• Resistance: The AD5272BRMZ-50 features a 50 kΩ end-to-end resistance with a ±1% tolerance, providing precise control over resistance settings.
• Resolution: It boasts a 1024-position resolution, allowing for fine adjustments and high accuracy in resistance settings.
• Interface: This digital potentiometer utilizes an I²C-compatible serial interface, ensuring easy integration with microcontrollers and other digital systems.
• Memory: It includes a non-volatile memory (EEPROM) for storing the initial startup resistance value, which is beneficial for applications that require a specific startup state.
• Power Supply: Operating with a wide power supply range of 2.7V to 5.5V, the AD5272BRMZ-50 is suitable for both 3V and 5V systems.
• Package: The device comes in a compact 10-lead MSOP (Mini Small Outline Package), which is ideal for space-constrained applications.

Applications:

The AD5272BRMZ-50 is designed to be a versatile component for various applications, including:

• Automated calibration systems
• Transducer adjustments
• Programmable filters and delays
• Power supply adjustments
• Offset and gain control

Reliability and Support:

Analog Devices Inc. is well-known for its commitment to quality and support. The AD5272BRMZ-50 is backed by comprehensive technical documentation, including datasheets, application notes, and design resources, to assist engineers in integrating this component into their designs seamlessly. With its robust feature set and dependable performance, the AD5272BRMZ-50 stands out as an excellent choice for precision resistance adjustments in electronic systems.
