AD5262BRUZ20 Digital Potentiometer from Analog Devices Inc.

The AD5262BRUZ20 is a precision digital potentiometer designed and manufactured by Analog Devices Inc., a leader in high-performance semiconductors. This digital potentiometer provides a compact and reliable solution for applications requiring variable resistor settings. The AD5262BRUZ20 features a dual-channel configuration, with each channel offering a resistance of 20 kΩ.

This digital potentiometer utilizes a versatile I²C-compatible interface, enabling easy integration into a wide range of systems. The non-volatile memory ensures that resistance settings are retained even when the power is turned off, making it an ideal choice for settings that need to be preserved across power cycles.

The device operates over a broad voltage range of 2.7V to 5.5V, which makes it suitable for use in both 3V and 5V systems. Its temperature range of -40°C to +85°C ensures reliable operation across diverse environmental conditions. The AD5262BRUZ20 is housed in a compact TSSOP-14 package, optimizing board space without sacrificing performance.

Key features of the AD5262BRUZ20 include:

• Dual 20 kΩ potentiometers
• I²C-compatible serial interface
• Non-volatile memory for storing settings
• Wide operating voltage range of 2.7V to 5.5V
• Extended temperature range of -40°C to +85°C
• Compact TSSOP-14 package
• Low temperature coefficient for stable performance

Applications for the AD5262BRUZ20 are diverse and can include adjustable power supplies, LCD screen calibration, audio control, industrial automation systems, and other electronic adjustments where precise control of resistance is required.

With its combination of precision, versatility, and reliability, the AD5262BRUZ20 is a highly effective solution for designers looking to add adjustable resistive elements to their electronic designs. Analog Devices Inc. continues to provide innovative and high-quality components that meet the demanding requirements of modern electronic systems.
