77311-118-02LF Real Image
Same model may have multiple batches, images only for reference.

77311-118-02LF

Part No 77311-118-02LF
Manufacturer Amphenol
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 2POS 2.54MM / Connector Header Through Hole 2 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Amphenol ICC (FCI)
Series BERGSTIK®
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 2
Number of Rows 1
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.230" (5.84mm)
Contact Length - Post 0.120" (3.05mm)
Overall Contact Length 0.450" (11.43mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold or Gold, GXT™
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Thermoplastic
Temperature Range - Operating -65°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A per Contact
Contact Finish Thickness - Post 78.7µin (2.00µm)
Base Product Number 77311
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 77311-118-02LF-ND,7731111802LF,609-4434
Standard Package 1,000
Win Source Part Number 1190797-77311-118-02LF
Ultra Librarian 3D Model Ultra Librarian 77311-118-02LF CAD Model

Description

The BERGSTIK® connector series is a 2-position male pin header that is designed to be mounted on a printed circuit board.

  • Positions: 2
  • Fastening Type: Push-Pull
  • Contact Material: Phosphor Bronze
  • Connector Type: Unshrouded
  • Pitch-Mating: 0.100" (2.54mm)
  • Contact Finish-Mating: Gold or Gold, GXT™ with a thickness of 30.0µin (0.76µm)
  • Contact Finish-Post: Tin with a thickness of 78.7µin (2.00µm)
  • Mounting Type: Through Hole
  • Temperature Range: -65°C to 125°C
  • Current Rating: 3A per contact
  • REACH: Affected
