ACA3102E14S-2PB Amphenol Industrial Operations
Same model may have multiple batches, images only for reference.

ACA3102E14S-2PB

Part No ACA3102E14S-2PB
Manufacturer Amphenol Industrial Operations
Catalog Circular Connectors - Assemblies
Description CONN RCPT MALE 4P SILV SLDR CUP / 4 Position Circular Connector Receptacle, Male Pins Solder Cup
Datasheet
ACA3102E14S-2PB Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Circular Connectors - Circular Connector Assemblies
Mfr Amphenol Industrial Operations
Series ACA-B, MIL-5015 Derivative
Package Bulk
Product Status Active
Connector Type Receptacle, Male Pins
Number of Positions 4
Shell Size - Insert 14S-2
Mounting Type Panel Mount
Mounting Feature Flange
Termination Solder Cup
Fastening Type Reverse Bayonet Lock
Orientation N (Normal)
Primary Material Metal
Shell Material Aluminum Alloy
Shell Finish Olive Drab Cadmium
Contact Finish - Mating Silver
Color Olive Drab
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Unshielded
Cable Opening 0.756" (19.20mm)
Temperature Range - Operating -55°C ~ 125°C
Contact Material Copper Alloy
Insert Material Polychloroprene
Applications Automation, Industrial, Instrumentation, Testing Equipment
Base Product Number ACA3102
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4020
Win Source Part Number 791329-ACA3102E14S-2PB
Ultra Librarian 3D Model Ultra Librarian ACA3102E14S-2PB CAD Model

Description

The Amphenol Industrial Operations ACA3102E14S-2PB is a circular connector assembly.

  • Series: ACA-B (MIL-5015 derivative)
  • Applications: Automation, Industrial, Instrumentation, Testing Equipment
  • Type: Receptacle
  • Gender: Male Pins
  • Termination: Solder Cup
  • Locking: Reverse Bayonet
  • Color: Olive Drab
  • Ingress Protection: IP67 (Dust Tight, Waterproof)
  • Contact Material: Copper Alloy
  • Shell Material: Aluminum Alloy
  • Insert Material: Polychloroprene
  • Operating Temperature: -55°C to 125°C
