XC7Z030-1FBG484C Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - System On Chip (SoC)
Mfr AMD Xilinx
Series Zynq®-7000
Package Tray
Architecture MCU, FPGA
Core Processor Dual ARM® Cortex®-A9 MPCore™ with CoreSight™
RAM Size 256KB
Peripherals DMA
Connectivity CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Speed 667MHz
Primary Attributes Kintex™-7 FPGA, 125K Logic Cells
Temperature Range - Operating 0°C ~ 85°C (TJ)
Package / Case 484-BBGA, FCBGA
Supplier Device Package 484-FCBGA (23x23)
Number of I/O 130
Base Product Number XC7Z030
MSL Level 4 (72 Hours)
REACH Status REACH Unaffected
ECCN 3A991D
HTSUS 8542.39.0001
Other Names 122-1894
Standard Package 1
Win Source Part Number 999420-XC7Z030-1FBG484C
Ultra Librarian 3D Model Ultra Librarian XC7Z030-1FBG484C CAD Model

Description

The XC7Z030-1FBG484C is a Kintex™-7 FPGA that comes with 125K logic cells.

  • Series: Zynq™-7000
  • Processor: dual-core ARM® Cortex®-A9 MPCore™ processor with CoreSight™ technology
  • Speed: 667MHz
  • RAM Size: 256KB
  • Connectivity: CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, and USB OTG
  • Peripherals: DMA peripherals
  • I/O ports: 130
  • Temperature Range: 0°C to 85°C (TJ)
  • Package: tray
