AZ1045-04F Amazing
Same model may have multiple batches, images only for reference.

AZ1045-04F

Part No AZ1045-04F
Manufacturer Amazing
Catalog TVS - Diodes
Description LOW CAP ESD HIGH SPEED 4-CH 5V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Unidirectional Channels 4
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Breakdown (Min) 6V
Voltage - Clamping (Max) @ Ipp 12V (Typ)
Power Line Protection No
Applications HDMI
Temperature Range - Operating -55°C ~ 85°C (TC)
Mounting Type Surface Mount
Package / Case 10-UFDFN
Supplier Device Package DFN2510P10E
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 66425-AZ1045-04F
Ultra Librarian 3D Model Ultra Librarian AZ1045-04F CAD Model

Description

AZ1045-04F

The AZ1045-04F component is a specialized part designed to handle higher loads and provide superior protection to further enhance the lifespan of your electronic projects.

Features and Benefits

  • Handles high electrical loads
  • Enhanced surge protection
  • Flexible application capabilities
  • Robust and durable construction

Applications

  • Heavy machinery
  • Automotive electronics
  • Power distribution systems
  • High-voltage applications

This component is perfect for applications where electrical surges are frequent and must be controlled for optimal performance.
