Same model may have multiple batches, images only for reference.

SKQGABE010

Name: SKQGABE010
Brand: ALPS Electric
SKU: 324686
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SKQGABE010
Manufacturer	ALPS Electric
Catalog	Tactile Switches
Description	SWITCH TACT SPST-NO .05A 12VDC / Tactile Switch SPST-NO Top Actuated Surface Mount
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Switches - Tactile Switches
Mfr	ALPS Electric
Series	SKQG
Package	Tape & Reel
Product Status	Active
Circuit	SPST-NO
Switch Function	Off-Mom
Contact Rating @ Voltage	0.05A @ 12VDC
Actuator Type	Standard
Mounting Type	Surface Mount
Actuator Height off PCB, Vertical	1.50mm
Actuator Orientation	Top Actuated
Termination Style	Gull Wing
Outline	5.20mm x 5.20mm
Illumination	Non-Illuminated
Operating Force	160gf
Temperature Range - Operating	-40°C ~ 90°C
Switch Travel	0.25mm
Mechanical Life	1,000,000 Cycles
Base Product Number	SKQGA
Standard Package	4,000 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8536.50.9031
Win Source Part Number	324686-SKQGABE010
Ultra Librarian 3D Model	Ultra Librarian SKQGABE010 CAD Model

Description

The ALPS Electric 324686-SKQGABE010 is a tactile switch from the SKQG series.

Termination Style: Gull wing
Package: tape & reel
Circuit: SPST-NO
Switch Function: off-mom
Actuator Type: standard
Switch Travel: 0.25mm
Contact Rating: 0.05A @ 12VDC
Actuation: Top
Outline: 5.20mm x 5.20mm
Illumination: Non-illuminated
Operating Force: 160gf
Temperature Range: -40°C to 90°C
Mechanical Life: 1,000,000 cycles
Offers: reliable performance and excellent tactile feedback.
